Adjustable Tri-bracket Pv Roof Structure

Adjustable Tri-bracket Pv Roof Structure

Aluminum ad tri-bracket solar roof structure made in China!!! 1.Product Intorduction Flat roof racking system is developed to mount the module tilt a certain angle on a flat roof or ground. You can have the fixed or adjustable angle solution as 10-15deg,15 30deg and 30-60deg according to your...






Aluminum ad tri-bracket solar roof structure made in China!!!


   1.Product Intorduction


Flat roof racking system is developed to mount the module tilt a certain angle on a flat roof or ground. You can have the fixed or adjustable angle solution as 10-15deg,15 30deg and 30-60deg according to your exact requirement. Series product have the innovated aluminum rail, D-module, clamps and legs which can be pre assembly to make the installation easy and quick for saving your labor cost and time. Besides,the customized length of rail will not require onsite weld andcut, keeping the appearance entirety, structural strength and anti-corrosive performance.














2.Product Specification




3.Product Details






4.Product Feature


Easy Installation

      D-module can be put into SR-Rail from any position. Sothe parts can be pre-assembled on factory to save yourinstall time on site.


 Flexibility and Compatible

       SR-Rail and its accessories can be installed with themost solar panels on the different conditions.


 Safety and Reliability

       The racking systems can stand up to the extreme weather complied with the AS/NZS  1170 and other international structure load standards by skilled engineers. The mainsupport components have also been tested to guarantee its structure and load-carrying capacity.






 5.Product Application







 6.Quality Control



certificate



Our Campany



















7.Necessary info. for us to design and quote


• What is your pv panels dimension?___mm Length x___mm Width x__mm Thickness
• How many panel are you going to mount? _______Nos.
• What's the tilt angle?____degree
• What is your planned pv assmebly block? ________Nos. in a row
• How is weather there,such as wind speed and snow load?
___m/s anit-wind speed and____KN/m2 snow load.
