Adjustable solar panel mounting system for metal roof Fast Installation Load transfers along the axis Strong aluminium alloy structure Reasonable component angle mounting bracket Provide multiple combinations describe Shadow distances that need to be preserved in multi-angle installation...

Product Details

                            Adjustable solar panel mounting system for metal roof


Fast Installation

Load transfers along the axis

Strong aluminium alloy structure

Reasonable component angle mounting bracket

Provide multiple combinations

solar panel base adjustable tilt system



Adjustable Tilt.jpg

adjustable solar PV system.jpg

describe

Shadow distances that need to be preserved in multi-angle installation directly determine the row spacing. by

Considering both the shading distance and the most effective use of the site, it is necessary to arrange a continuous installation.

Bottom beam. When the roof slopes East-West or inclines south, but the roof has rafters, in a particular case

The independent flat roof bracket can also be directly installed on the roof. Purlin north-south and roof

It is usually not feasible to install pillars directly on flat roofs with rafters going East-West or south.

Yes. In this case, we will use the original roof structure, with double-headed bolts or FixT/FixE will

Flat roof brackets are directly fixed to wood or steel structures.

This product is only an economical small-scale system in the multiple product portfolio of Wanhos, but it saves money.

Installation time has been set up. Optimizing by connecting flat roof brackets directly to load-bearing structures of buildings

Load conduction of the system. In many cases, only two fasteners are required for each flat roof bracket. Because of the snowstorm

Three to four fasteners may be required to ensure stability in the case of increased load due to load. whatever

In this case, the joints should be located near the pillar joints. All standard brackets are suitable for this purpose.

Style. If there is any demand, we will be very happy to provide you with this design.


Specification



lnstall SiteLow profile roof of open field
Tilt Angle10deg-60deg
Building HeightUp to 20m
Max Wind SpeedUp to 60m/s
Snow LoadUp to1.4KN/m2
standardsAS/NZS 1170 & DIN 1055 & Other
MaterialAluminum alloy & Stainless steel
ColorNatural
Anti-corrosiveAnodized
WarrantyTen years warranty
DurationMore than 20 years



Project Pictures



solar panel base adjustable tilt system



  solar panel base adjustable tilt system



solar panel base adjustable tilt system

We specialize in PV mounting systems. including Rooftops Mountings and Ground Mounting systems.

We have passed ISO9001,and our products has passed AS/NZS, SGS, MCS certificates.As a large manufacturer of industry and trade. We guarantee the quality and quantity of our products.We are very confident that you can rely on us as a capable vendor.


Features:


1.Easy Installation:D-module can be put into SR-Rail from any position.

2.Flexibility and Compatible:
SR-Rail and its accessories can be installed with the most solar panels on the different condition.

3.Safety and Reliability:AS/NZS 1170 ,SGS

4.Excellent water-proof performanace

5.High anti-corrosion property,light and high intensity

6.Customized





solar panel base adjustable tilt system





solar panel base adjustable tilt system_21





Necessary info. for us to design and quote

• What is your PV panels dimension?___mm Length x___mm Width x__mm Thickness
• How many panels are you going to mount? _______Nos.
• What's the tilt angle?____degree
• What is your planned PV assembly block? ________Nos. in a row
• How is weather there, such as wind speed and snow load?
___m/s anti-wind speed and____KN/m2 snow load.
