WANHOS SOLAR POLE MOUNTING SYSTEM Materail:Q235B with AL6005-T5 Surface treatment:Hot galvanized Warranty:10 Years

Product Details

pole mounted solar panels ground install



pole mounted solar panels ground install


Pole Mounting System is designed to install solar panels on a single pole . According to different conditions , several kinds of solutions are available.Wanhos Solar Pole Mounting System takes the importance of safety and duration . The systems have been calculated compatible with the structural machines and tested strictly . Materials used include galvanized steel and anodized aluminum , with great anti-corrosion suitable for outdoor using.




pole mounted solar panels ground install




pole mounted solar panels ground install



        Easy to install. The tilt-in module can be put into the extruded rail from the any location and can be high pre-assembly with the clamp to minimize the time and cost of installation. The high integrated support structure just need a few bolts to fasten together.

  Offer unmatched durability: with all structural components comprised of high class stainless steel, anodized aluminum alloy and the double anticorrosive finish for the steel pipe and cap, it is designed for twenty years service life and backed by ten years warranty.

  Stand up to extreme weather. The Wanhos solar ground mount system is designed to stand up to the extreme weather complied with the AS/NZS 1170 and other international structure load standard by the skilled engineers. The main support components also have been test to guaranty its structure and load-carrying capacity.

  Provide broad installation flexibility. These systems accommodate most commercially available framed solar panels and diverse foundation solution, and they can scale easily from small to large, multi-megawatt installations.pole mounted solar panels ground install


pole mounted solar panels ground install

pole mounted solar panels ground install




pole mounted solar panels ground install

pole mounted solar panels ground install




pole mounted solar panels ground install

pole mounted solar panels ground install




Installation siteOpen ground
Tilt Angle10~60deg
System Height<2.5m
Max Wind Speed<60m/s
Snow Load<1.4KN/m2
StandardAS/NZS 1170 and other international Standard
MaterialAluminum alloy Al6005-T5& Stainless steel 304 & Hot galvanized steel
AnticorrosiveAnodized & Hot galvanized
ColorNatural or Optional
WarrantyTen years warranty and up twenty years service life



_16





Xiamen Wanhos Solar Technology Co., Ltd. is a hightech enterprise in solar PV field specializing in solar PV products with advanced technology and excellent service. Wanhos Solar members devote themselves to research, design, manufacture and sell the steady, trustable and costefficient solar PV mounting system solutions. As one of the largest PV solar products exporter in China, the pioneering products have been installed in more than100 countries and regions since it established.




 Certification

pole mounted solar panels ground install



Workshop

pole mounted solar panels ground install





pole mounted solar panels ground installpole mounted solar panels ground install





Necessary information Design and estimate

1.What are the dimensions of your pv panel?

___ mm length x ___ mm width x _ _ mm thickness

2.How many panels do you attach? _______No.

3.What is the tilt angle?

4.Is your planned PV probably a block? ________No. In a row

5.How is the weather, such as wind speed and snowfall?

___ m / s wind speed and ____ KN / m 2 snow load.







pole mounted solar panels ground install
